| Мощность, кВт |
Частота вращения выходного вала, об/мин |
Крутящий момент, Н*м |
Переда- точное число |
Вес, кг |
|---|---|---|---|---|
| 0.18 | 10.3 | 158 | 135.58 | 16 |
| 12.0 | 135 | 116.1 | ||
| 13.8 | 117 | 100.74 | ||
| 14.8 | 109 | 94.2 | ||
| 16.8 | 96 | 82.92 | ||
| 18.9 | 85 | 73.52 | ||
| 21.2 | 76 | 65.56 | ||
| 23.7 | 68 | 58.74 | ||
| 29.2 | 55 | 47.66 | ||
| 33.2 | 49 | 41.91 | ||
| 0.25 | 14.8 | 152 | 94.2 | 17 |
| 16.8 | 134 | 82.92 | ||
| 18.9 | 119 | 73.52 | ||
| 21.2 | 106 | 65.56 | ||
| 23.7 | 95 | 58.74 | ||
| 29.2 | 77 | 47.66 | ||
| 33.2 | 68 | 41.91 | ||
| 37.2 | 60 | 37.38 | ||
| 41.5 | 54 | 33.49 | ||
| 0.37 | 29.2 | 114 | 47.66 | 17 |
| 33.2 | 100 | 41.91 | ||
| 37.2 | 89 | 37.38 | ||
| 41.5 | 80 | 33.49 | ||
| 56.0 | 60 | 24.93 | ||
| 65.0 | 51 | 21.35 | ||
| 75.0 | 44 | 18.53 | ||
| 80.0 | 41 | 17.33 | ||
| 0.55 | 37.0 | 133 | 37.38 | 20 |
| 42.0 | 119 | 33.49 | ||
| 56.0 | 90 | 24.93 | ||
| 65.0 | 77 | 21.35 | ||
| 75.0 | 67 | 18.53 | ||
| 80.0 | 63 | 17.33 | ||
| 92.0 | 55 | 15.25 | ||
| 104.0 | 49 | 13.52 | ||
| 116.0 | 44 | 12.06 | ||
| 130.0 | 39 | 10.8 | ||
| 0.75 | 65.1 | 106 | 21.35 | 21 |
| 75.0 | 92 | 18.53 | ||
| 80.2 | 86 | 17.33 | ||
| 91.1 | 75 | 15.25 | ||
| 102.8 | 67 | 13.52 | ||
| 115.3 | 60 | 12.06 | ||
| 128.7 | 53 | 10.8 | ||
| 158.5 | 43 | 8.77 | ||
| 180.3 | 38 | 7.71 | ||
| 202.0 | 34 | 6.88 | ||
| 225.6 | 30 | 6.16 | ||
| 1.1 | 91.8 | 110 | 15.25 | 27 |
| 103.6 | 97 | 13.52 | ||
| 116.1 | 87 | 12.06 | ||
| 129.6 | 78 | 10.8 | ||
| 159.6 | 63 | 8.77 | ||
| 181.6 | 56 | 7.71 | ||
| 203.5 | 50 | 6.88 | ||
| 227.3 | 44 | 6.16 | ||
| 280.0 | 36 | 5 | ||
| 1,5 | 159.6 | 86 | 8.77 | 30 |
| 181.6 | 76 | 7.71 | ||
| 203.5 | 68 | 6.88 | ||
| 227.3 | 61 | 6.16 | ||
| 280.0 | 49 | 5 | ||
| 2.2 | 284.0 | 71 | 5 | 33 |
